Bộ chuyển đổi tín hiệu signal converter Model MR-PMC3, MIRAE E&I
제품크기 Small size(mm) | 83(H), 51(W), 102mm(D) |
---|---|
절연 Isolation | input to output to power supply. |
취부방식 Wiring | teminal socket wiring. |
외함재질 Case & color | black ABS plastic case. |
제품무게 Weight | about 400g |
사용온도 Operating ambient temperature | 0 - 50℃ |
보관온도 Non operating ambient temperature | -20 ~ 80℃ |
온도오차 Temperature coefficient | 0.015%/℃ |
동작습도 Operating ambient humidity | 90% RH max.(non condensing) |
절연저항 Insulation resistance | greater than 100Mohm with 500VDC |
절연내압 Dielectric strength | 1500VAC @ 1minute (input to outut to power) |
변환오차 Conversion accuracy | 0.15% max. |
응답속도 Response time | 0 - 90% |
