Bộ chuyển đổi tín hiệu signal converter Model MR-PSC, MR-PSC2, MIRAE E&I
Frequency, pulse divider, square root extraction type input
Instruction specifications: 3digit FND (RED) (OPTION)
Power specifications: AC 110V/220V 50/60Hz, DC24V (OPTION)
- Product size Small size(mm): 83(H), 51(W), 102mm(D)
- Isolation: input to output to power supply.
- Installation method Wiring: terminal socket wiring.
- Enclosure material Case & color: black ABS plastic case.
- Product weight: about 400g
- Operating ambient temperature: 0 - 50℃
- Storage temperature Non operating ambient temperature: -20 ~ 80℃
- Temperature error Temperature coefficient: 0.015%/℃
- Operating ambient humidity: 90% RH max.(non condensing)
- Insulation resistance: greater than 100Mohm with 500VDC
- Dielectric strength: 1500VAC @ 1minute (input to output to power)
- Conversion accuracy: 0.15% max.
- Response time: 0 - 90% (0.5sec)
