sensor input   PT-100Ω (3wires) (4CH)
Temperature measurement range   -20℃~230℃
precision / scale  ±1℃(Full Scale) / 0.1℃
Caution, alarm output:  10A 250VAC, 10A 30VDC (Max.)
FAN output: 16A 250VAC, 16A 30VDC (Max.)
Sensor fault output:  10A 250VAC, 10A 30VDC (Max.)
Communication RS-485:  MODBUS-RTU, ASCII (our company) (4800, 9600, 19200 bps selectable - when SS.U is selected)
Communication 4~20mA DC
  1) Current output for the current peak temperature value
  2) Circulating current output for R, S, T temperature values (time: 9 sec, 7 sec)
Product size (panel cutting size:  153(W) X 92(H) X 148 (D)mm (136(W) X 75(H)mm)
Control power/power consumption:  AC100 ~ 240V (50/60Hz) or 100-130Vd.c. / 9W
Reliability and Certification: According to IEC61000-4, IEC61010-1, CE, CB, C_UL
product weight:  760g
Other: Case material ABS flame retardant
