Instrumentation

Sensor input PT-100Ω (3Wires)

3 CH (can choose out of1CH~4CH)

Temperature measurement range - 20 ℃ ~ 230 ℃ Measurement for 200ms

Precision / scale ±0.5 ℃(Full Scale) / 0.1 ℃

Major functions

1) Always display the PEAK temperature value

2) Attention and alarm functions (Alarm 1 and Alarm 2) Relay output available

3) FAN control function (AUTO and MANUAL functions) Relay output available

4) Function to decide whether SENSORS are abnormal or not Relay output available Output

Output for attention and alarm 10A 250VAC, 10A 30VDC(Max.) Alarm 1, Alarm 2

FAN output 16A 250VAC, 16A 30VDC(Max.)

SENSOR FAULT Output 10A 250VAC, 10A 30VDC(Max.) either sensor error or wire misconnected

POWER OFF Output 10A 250VAC, 10A 30VDC(Max.) either product adnormal or power off

Communication function

RS-485 MODBUS-RTU(4800, 9600, 19200bps Possible to choose)4~20mA DC

1) Current output for the present PEAK temperature value 0 ℃ ~ 200 ℃

2) circulating current output regarding R, S, T phase (can be changeable) temperature values

Product size / Panel cutting size 153(W) Ⅹ 92(H) Ⅹ 148(D)mm (136(W) Ⅹ 75(H)mm)

Control power / Power consumption AC100 ~ 240V(50/60Hz) or 100-130Vd.c. / 9W

Reliability and certification According to IEC61000-4 and IEC61010-1, CE, CB EMC, safety

Product weight 790g

Etc. The case is made of frame retarding ABS materials.
