P2-500CSM
For-phase, operate multi-fan, able to measure the lightening and leakage current
Instrumentation
Sensor input PT-100Ω (3Wires) 4 CH (can choose out of 1CH~4CH)
Measurement scale for temperature, leakage, lightening
Temperature : - 40 ℃ ~ 250 ℃,
Leakage : 0 ~ 40[mA], Lightening : 40 ~ 400[A]
Leakage & Lightening input ZCT 1, ZCT 2 input 2CH ( measure simultaneously) leakage and lighting can
Precision / scale
Temperature: ±0.5 ℃(FS) / 0.1 ℃ Measurement for 200ms
Leakage: ±5 %(FS) / 0.1[mA],
Lightening : ±5 %(FS) / 1[A]
Major functions
1) Always display the PEAK temperature value LCD first applied
2) Measurement of leakage current and the
number and size of lightening
Indicate and record
date and time
3) Attention and alarm functions(Functions of
Alarm 1 and Alarm 2) Relay output available
4) FAN control function(AUTO and MANUAL unctions)
Actuation of multi fans(Judgment on whether there
is a fault or not and displaying actuation time)
Relay output available
5) Function to decide whether SENSORS are
abnormal or not Relay output available
6) Operating date and frequency of Alarm 2 can
be recorded each 30 times
Output
Output for attention and alarm 10A 250VAC, 10A 30VDC(Max.) Alarm 1, Alarm 2
FAN 1 Output 16A 250VAC, 16A 30VDC(Max.) FAN 1
FAN 2 Output 16A 250VAC, 16A 30VDC(Max.) FAN 2
SENSOR FAULT 10A 250VAC, 10A 30VDC(Max.) either product adnormal or power
Communication
function
RS-485 MODBUS-RTU
(4800, 9600, 19200bps Possible to choose)
4~20mA DC
1) Current output for the present PEAK
temperature value 0 ℃ ~ 200 ℃
2) circulating current output regarding R, S, T phase (can be changeable)
temperature values (Time: 9, 7, 5 second)
Product size / Panel cutting size 153(W) Ⅹ 92(H) Ⅹ 148(D)mm (136(W) Ⅹ 75(H)mm)
Control power / Power consumption AC100 ~ 240V(50/60Hz) or 100-130Vd.c. / 9W
Reliability and certification According to IEC61000-4 and IEC61010-1, CE, CB EMC, safety
Product weight 910g
Etc. The case is made of frame retarding ABS materials.
