P3-400 For 4-phase, European model

Instrumentation

Sensor input PT-100Ω (3Wires) 4 CH (can choose out of 1CH~4CH)

Temperature measurement range - 20 ℃ ~ 230 ℃ Measurement for 200ms

Precision / scale ±1 ℃(Full Scale) / 0.1 ℃

Major functions

1) Always display the PEAK temperature value

2) Attention and alarm functions (Alarm 1 and Alarm 2) Relay output available

3) FAN control function (AUTO and MANUAL functions) Relay output available

4) Function to decide whether SENSORS are abnormal or not Relay output available

Output

Output for attention and alarm 10A 250VAC, 10A 30VDC(Max.) Alarm 1, Alarm 2

FAN output 16A 250VAC, 16A 30VDC(Max.)

SENSOR FAULT Output 10A 250VAC, 10A 30VDC(Max.) either product adnormal or power off

Communication function

RS-485 MODBUS-RTU, ASCII(Our company) (Fixed as 9600bps) 4800, 19200bps option 4~20mA DC

1) Current output for the present PEAK temperature value 0 ℃ ~ 200 ℃

2) circulating current output regarding R, S, T phase (can be changeable) temperature values (Time: 9, 7, 5 second)

Product size / Panel cutting size 100(W) Ⅹ 100(H) Ⅹ 122(D)mm (91(W) Ⅹ 91(H)mm)

Control power / Power consumption AC100 ~ 240V(50/60Hz) or 100-130Vd.c. / 9W

Reliability and certification According to IEC61000-4 and IEC61010-1, CE, CB EMC, safety

Product weight 700g

Etc. The case is made of frame retarding ABS materials
