Bộ mã hoá vòng quay CRK66-4096R4096C1M01 TWK-ELEKTRONIK, CRK66-4096R4096C1M01 TWK-ELEKTRONIK, CRK66-4096R4096C1M01, TWK-ELEKTRONIK
Electrical data
Sensor system: GaAlAs diodes, photo-transistor
array
Resolution: 8192 positions revolution, max.
Measuring range: 4096 revolutions
Total number of
positions: 225 (25 Bits)
Graduation code: Gray
Max. position variance: ≤ 2' 38" at 4096 positions/rev.
≤ ±1'59 at 8192 positions/rev.
Output code: Natural binary or Gray
Code sense: CW or CCW; (programmable)
Supply voltage range: + 13,5 VDC to + 30 VDC
Power consumption: PD ≤ 3,5 W
(Inrush current ≤ 300 mA)
Interface: Line driver in acc. with RS 485; galvanic separation is achieved with
an opto-coupler. Supply voltage
galvanic separation is achieved
with DC/DC-converter
Electromagnetic
compatibility (EMC): EN 61000-4-2 (ESD), EN 61000-
4-4 (Burst), EN 61000-6-4 (Emission)
Mechanical data
Operating speed: 3000 rpm max. (continuous)
4000 rpm max. (short period)
Angular acceleration: 105 rad/s² max.
Moment of inertia (rotor): 45 gcm²
Operating torque: ≤ 5 Ncm (8 Ncm - CRD 66)
(at 1000 rpm)
Starting torque: ≤ 1 Ncm (4 Ncm - CRD 66)
Permissible shaft load: 250 N max. (axial and radial)
Bearing life expectancy: 109 revolutions *
Mass: ca. 0.5 kg with round connector
ca. 0.7 kg with connecting cap
