Measuring method

Spectral Measurement in the UV-VIS Range (200 – 720 nm)

Measuring gap
(optical layer thickness)

1 mm

5 mm

1 mm

5 mm

Application (optimized for)

Municipal wastewater:

Municipal wastewater:

Municipal wastewater:

Municipal wastewater:

Measuring range and Resolution

Inlet:

Inlet:

COD _total

0 ... 20,000 mg/l 1 mg/l

0 ... 20,000 mg/l 1 mg/l

COD _dissolv

0 ... 12,500 mg/l 1 mg/l

0 ... 12,500 mg/l 1 mg/l

TOC

0 ... 20,000 mg/l 1 mg/l

0 ... 20,000 mg/l 1 mg/l

DOC

0 ... 12,500 mg/l 1 mg/l

0 ... 12,500 mg/l 1 mg/l

BOD

0 ... 8,000 mg/l 1 mg/l

0 ... 8,000 mg/l 1 mg/l

SAC_{254 total}

0.0 ... 5,000 1/m 1 1/m

0.0 ... 5,000 1/m 1 1/m

SAC_{254 dissolv}

0.0 ... 3,000 1/m 1 1/m

0.0 ... 3,000 1/m 1 1/m

UVT_{254 total}*

0.0 ... 100.0 % 0.1 %

0.0 ... 100.0 % 0.1 %

UVT_254 dissolv*

0.0 ... 100.0 % 0.1 %

0.0 ... 100.0 % 0.1 %

TSS

0.00 ... 15.00 g/l 0.01 g/l

Aeration:

Aeration:

COD _dissolv

0 ... 12,500 mg/l 1 mg/l

0 ... 12,500 mg/l 1 mg/l

DOC

0 ... 12,500 mg/l 1 mg/l

0 ... 12,500 mg/l 1 mg/l

SAC_{254 total}

0.0 ... 5,000 1/m 1 1/m

0.0 ... 5,000 1/m 1 1/m

SAC_{254 dissolv}

0.0 ... 3,000 1/m 1 1/m

0.0 ... 3,000 1/m 1 1/m

UVT_{254 total}*

0.0 ... 100.0 % 0.1 %

0.0 ... 100.0 % 0.1 %

UVT_254 dissolv*

0.0 ... 100.0 % 0.1 %

0.0 ... 100.0 % 0.1 %

TSS

0.00 ... 20.00 g/l 0.01 g/l

Effluent:

Effluent:

Effluent:

Effluent:

COD _total

0 ... 4,000 mg/l 1 mg/l

0.0 ... 800.0 mg/l 0.1 mg/l

0 ... 4,000 mg/l 1 mg/l

0.0 ... 800.0 mg/l 0.1 mg/l

COD _dissolv

0 ... 4,000 mg/l 1 mg/l

0.0 ... 800.0 mg/l 0.1 mg/l

0 ... 4,000 mg/l 1 mg/l

0.0 ... 800.0 mg/l 0.1 mg/l

TOC

0 ... 2,500 mg/l 1 mg/l

0.0 ... 500.0 mg/l 0.1 mg/l

0 ... 2,500 mg/l 1 mg/l

0.0 ... 500.0 mg/l 0.1 mg/l

DOC

0 ... 2,500 mg/l 1 mg/l

0.0 ... 500.0 mg/l 0.1 mg/l

0 ... 2,500 mg/l 1 mg/l

0.0 ... 500.0 mg/l 0.1 mg/l

BOD

0 ... 2,500 mg/l 1 mg/l

0.0 ... 500.0 mg/l 0.1 mg/l

0 ... 2,500 mg/l 1 mg/l

0.0 ... 500.0 mg/l 0.1 mg/l

SAC_{254 total}

0.0 ... 3,000 1/m 1 1/m

0.0 ... 600.0 1/m 0.1 1/m

0.0 ... 3,000 1/m 1 1/m

0.0 ... 600.0 1/m 0.1 1/m

SAC_{254 dissolv}

0.0 ... 3,000 1/m 1 1/m

0.0 ... 600.0 1/m 0.1 1/m

0.0 ... 3,000 1/m 1 1/m

0.0 ... 600.0 1/m 0.1 1/m

UVT_{254 total}*

0.0 ... 100.0 % 0.1 %

0.0 ... 100.0 % 0.1 %

0.0 ... 100.0 % 0.1 %

0.0 ... 100.0 % 0.1 %

UVT_254 dissolv*

0.0 ... 100.0 % 0.1 %

0.0 ... 100.0 % 0.1 %

0.0 ... 100.0 % 0.1 %

0.0 ... 100.0 % 0.1 %

TSS

0 ... 4,500 mg/l 1 mg/l

0.0 ... 900.0 mg/l 0.1 mg/l

Flow rate

≤ 3 m/s

Pressure Resistance

Maximum 1 bar (incl. sensor connection cable)

Electrical connections

2-wire shield cable with quick fastener to sensor

Electromagnetic
Compatibility

EN 61326, Class B, FCC Class A
Intended for indispensable operation

Certifications

CE

Mechanical

Housing: Titan Grade 2, PEEK; Window: Sapphire glass
Protection class: IP 68

Weight (without cable)

Approx. 8.82 lb (4 kg)

Warranty

2 years for defects in quality
