Accuracy class 1

Nominal characteristic value (sensitivity) 1 m V/V

Combined error < 1%

Characteristic value tolerance 0.2%

Measuring principle Full bridge strain gauge

Nominal resistance of the strain gauge bridge 700 Ohm

Bridge supply voltage

Nominal value 10 V

Max. permissible value 14 V

Mechanical stop 1.8 to 2.4 FN dep. on type

Operating load 1.8 to 2.4 FN

Limit load 10xFN

Nominal measuring deflection 0.1 to 0.25 mm depending on type

Nominal temperature range -10 °C to +60 °C

Operating temperature range -10 °C to +90 °C

Temperature coefficient ±0.5% / 10 K (characteristic value)

±0.5% / 10 K (zero signal)

Protection class IP 54

Max. permissible axial transverse force 1xFN
