ports threads G 1/4 - G 3/4

function NC

pressure range 0-16 / 0-40 bar

KV value 2,5 m³/h

media gaseous  liquid  contaminated 

flow direction A B as marked

switching cycles 200 1/min

switching time opening 25 ms

closing 25 ms

media temperature DC -10 °C — +100 °C

AC -10 °C — +100 °C

ambient temperature DC -10 °C — +80 °C

AC -10 °C — +80 °C

weight 1,5 kg

nominal voltage Un 24 V DC +5% / -10%

Un 230 V 40-60 Hz AC +5% / -10%

actuation DC direct-current magnet

AC direct-current magnet with integrated rectifier

insulation rating H 180 °C

protection IP65

energized duty rating ED 100%

connection plug acc. DIN EN 175301-803, form A, 4 positions x 90°, wire diameter 6-8 mm

M12x1 connector acc. DESINA / VDMA
