Product Features

• Built-in PID control with auto-sleep and wake-up functions for pressure and temperature control applications.
• The digital output/input terminals can be programmed with 31 kinds of functions such as forward/reverse rotation, jog, multi-speed control, external fault, etc.
• Input signal reaction time can be adjusted and SINK/SOURCE mode is supported.
• Built-in 16-segment program operation function, can set cycle/time count/direction/time settings, etc.
• Support RS-485 communication control interface (Modbus RTU protocol).
• Built-in brake transistor; brake voltage level and braking capacity can be adjusted.
• Support V and F independent adjustment function for simple torque control of conventional torque motor.
• Two sets of analog input signals for addition, subtraction and gain control.
• The panel can display eight monitoring screens with 17 monitoring items to choose from.
• External keypad (KP-601A) can be connected. Remote control and parameter copying and memory functions are available.
• Multifunctional special key (SPEC) can simulate digital input terminal function.
