Features

Support both CAN 2.0A and CAN 2.0B specification

Fully compatible with the ISO 11898-2 standard

Rotary switch for CAN baud rate configuration

Up to 100 CAN nodes on the CAN channel (*Note)

Transmission distance up to 2 km at any CAN baud rate

Provides the 512-record CAN Tx buffer and 512-record CAN Rx buffer

Allow user-defined baud rate

Software utility tool for message filter configuration

Fiber Port: ST (Multi-mode)

Broken line detection for fiber cable

Note: We have verified to drive 100 CAN nodes at the same time via one CAN port of I-2533.
