C Group

RTD

PMC

Type

Range

Symbol

PT

Pt100Ω

-199.9 ~ 800.0°C

D-PT

JPt100Ω

-199.9 ~ 500.0°C

J-PT

PMC

0~100kΩ

0 ~ 100 kΩ

PMC

Ordering Code

SCONI-2300-5NX

SCN-230-5NX

Input

Various Input Signals

Ex. 0 ~ 5kΩ

(3-wire Potentiometer)

5

Output-1

DC 4 ~ 20mA

N

Output-2

None

Y

Power Supply

AC 85~264V (50~60Hz)

Ordering Code

SCONI-2300-5NY

SCN-230-5NY

Input

Various Input Signals

Ex. 0 ~ 5kΩ

(3-wire Potentiometer)

5

Output-1

DC 4 ~ 20mA

N

Output-2

None

Y

Power Supply

DC 24V

Ordering Code

SCONI-2300-52Y

SCN-230-52Y

Input

Various Input Signals

Ex. 0 ~ 5kΩ

(3-wire Potentiometer)

5

Output-1

DC 4 ~ 20mA

2

Output-2

DC 0 ~ 10V

Y

Power Supply

DC 24V

Ordering Code

SCONI-2300-22Y

SCN-230-22Y

Input

Various Input Signals

Ex. 0 ~ 5kΩ

(3-wire Potentiometer)

2

Output-1

DC 0 ~ 10V

2

Output-2

DC 0 ~ 10V

Y

Power Supply

DC 24V

1

DC 0 ~ 5V

2

DC 0 ~ 10V

3

DC 1 ~ 5V

4

DC 0 ~ 20mA

5

DC 4 ~ 20mA

6

DC 1 ~ 5mA

R

Other

1

DC 0 ~ 5V

2

DC 0 ~ 10V

3

DC 1 ~ 5V

4

DC 0 ~ 20mA

5

DC 4 ~ 20mA

6

DC 1 ~ 5mA

R

Other

X

AC 85~264V (50~60Hz)

Y

DC 24V (Option)
