Table 1: Actuator Models and Accessories
Product Code Number Description
Bộ điều khiển van JOHNSON CONTROLS M9108-GGA-2 70 lb∙in (8 N∙m) electric non-spring return actuator for proportional control with 0 to 10 VDC feedback
Bộ điều khiển van JOHNSON CONTROLS M9108-GGC-2 70 lb∙in (8 N∙m) electric non-spring return actuator for proportional control with two SPDT 24 VAC auxiliaryswitches and 0 to 10 VDC feedback
Bộ điều khiển van JOHNSON CONTROLS M9108-HGA-2 70 lb∙in (8 N∙m) electric non-spring return actuator for proportional control with 0 to 10 VDC feedback andadjustable zero and span
Bộ điều khiển van JOHNSON CONTROLS M9108-HGC-2 70 lb∙in (8 N∙m) electric non-spring return actuator for proportional control with two SPDT 24 VAC auxiliaryswitches, 0 to 10 VDC feedback, and adjustable zero and span
DMPR-KR003* Sleeve Pin Kit for Johnson Controls round dampers with a 5/16 in. (8 mm) diameter shaft
DMPR-KC003* Blade Pin Extension without Bracket for Johnson Controls D-1300 direct-mount applications
DMPR-KC254 Inside Frame Mounting Kit for Johnson Controls dampers that require the actuator within the airstream
M9000-103 14 VA Transformer, 120/24 VAC, 60 Hz, Class 2
M9000-104 14 VA Transformer, 230/24 VAC, 60 Hz, Class 2
M9000-150 Damper Mount Linkage Kit for remote inside duct mounting an M9108 actuator to a three-blade or largerdamper (not intended for a Johnson Controls damper)
M9000-151 Base Mount Linkage Kit for remote inside duct mounting
M9000-153 Crank Arm Kit for remote mounting
M9000-154 1 in. Jackshaft Coupler Kit for mounting on a 1 in. diameter damper shaft
M9000-155 Manual Handle for positioning a damper or valve when power is removed from an M9108 actuator
M9000-160 Replacement anti-rotation bracket for M9108 actuators
M9000-200 Commissioning Tool provides a control signal to drive on/off, floating, proportional, or resistive actuators
M9000-300 Weather Shield Enclosure protects M9108 actuators in outdoor damper applications
