SM24A-MA

Rotary actuator, 20 Nm, AC/DC 24 V, 4...20 mA, 150 s, IP54

Specifications

Voltage AC/DC AC/DC 24 V

Power consumption (running) 3.5 W

Power consumption (holding) 1.25 W

Power Consumption For Wire Sizing 6 VA

Connection Supply Control Cable 1 m, 4 x 0.75 mm²

Torque 20 Nm

Control type 4...20 mA

Direction Of Motion Motor selectable with switch 0/1

Manual override With push-button, can be locked

Angle of rotation 95

Running time (motor) 150 s / 90°

Running time motor variable 90...350 s

Mechanical interface Universal shaft clamp reversible 10...20 mm

Protection category IP54

Degree Of Protection NEMA NEMA 2

Enclosure Type UL Enclosure Type 2

Ambient Tempreture -30...50°C [-22...122°F]
