Cảm biến áp suất United Electric H100-218 UE Pressure Switch

0944911836 Ms. Duyên 0972835740 Ms. Hà 0385097045 Mr. Hiếu 0392468875 Ms. Anh 0707602728 Ms. Vân
Cảm biến áp suất United Electric  H100-218 UE Pressure Switch

Cảm biến áp suất United Electric H100-218 UE Pressure Switch

H100-218

UE Pressure Switch

Enclosure: Die cast aluminum, epoxy

powder coated, gasketed, captive cover

screws

Sensing Element: Phosphor bronze

bellows with nickel-plated brass

1/4” NPTF pressure connection.

Stainless steel spring exposed

to media.

Adjustable Range: 30 ”Hg Vac to 0 "wc

Deadband: 1 to 2 ”Hg

Over range Pressure: 3 psi

Proof Pressure: 30 psi

Switch Setting: Not Included

Switch Output: One SPDT.

Electrical Rating: 15A 125/250/480 VAC

resistive

Electrical Connection: 1/2” NPTF

Two 7/8” diameter knockouts

Classification: Enclosure type 4X

Approval: UL Listed, cUL Certified

UEC compliant to LVD, PED

  • United Electric H100-218
  • Liên hệ
  • 587
  • Thông tin sản phẩm
  • Bình luận

Cảm biến áp suất United Electric  H100-218 UE Pressure Switch

Sản phẩm cùng loại
