Technical Specifications
Accuracy: ±0,05% in weight of carbon within operating range.
Output: 1000 - 1200 mV in the normaloperating range.
Response time: Less than 5 seconds.
Operating temperature: Probe: 600 -1150°C. Head of the probe: Less than 150 °C.
Reference air: Dry and clean air: 50-100cc/minute.
Scavenging air: 2-3 liters/minute (clean and dry air). To be sent at intervals with variable frequency in function of the deposited carbon quantity.
Thermocouple: Type K or S.
Dimensions: Length mm. 500 and 650.
Diameter external tube: mm. 27.
Connection to process: 1” NPT M.
