Brand Hokuyo

Ambient Temperature Operation -10 to +50 Degree C,or less

Model Number DMS-GA1-V

Directional Mounting Head On

Transmission Distance 0 to 1m

Signals 4-bit

Directional angle 30 Degree

Transmission Method Half Duplex Two Way Transmission

Transmission Time 40 msec or less

Modulation Method Pulse Modulation

Power Source 24 V DC (10 to 30 V DC)

Current Consumption 100 mA Max.

Ambient Illuminance 4,000lux or less(Incandescent lamp)

Impact Resistance 500m/s2,each 10 time in X,Y and Z directions

Connection Lead wire 2m long

Protective Structure IP64(IEC standard)
