Technical data:

• Supply voltage (UB): 10 ÷ 30 Vdc

• Max ripple: 10%

• No-load supply current (Io): ≤ 10 mA

• Voltage drop (Ud): see ordering references

• Temperature range: – 25° ÷ +125°C

• Max thermal drift of sensing distance Sr

: ± 10%

• Repeat accuracy (R): 2%

• Switching hysteresis (H): 10%

• Degree of protection: IP67

• Cable conductor cross section: 0,35 mm2 on 6,5 – 8 – 12 mm

0,50 mm2 on 18 – 30 – 45 mm

• Protected against short-circuit and overload

• Protected against any wrong connection

• Suppression of initial false impulse

• Electromagnetic compatibility (EMC) according to EN60947-5-2

• Shock and vibration resistance according to EN60068-2-27 EN60068-2-6
