Standards EN ISO 13849-1;
IEC/EN 60947-5-1;
IEC/EN 60947-5-5; EN 418
Enclosure aluminium die-cast, enamel finish
Cover glass-fibre reinforced,
shock-proof thermoplastic,
ultramid
Degree of protection IP 65 to IEC/EN 60529
Contact material silver
Switching elements change-over contact with
double break
Switching system snap action, positive break
NC contact A
Connection screw terminals
Cable section max. 2.5 mm2
(incl. conductor ferrules)
Cable entry 2 x M20 x 1.5
B10d (10% Load) 200.000
TM max. 20 years
Uimp 6 kV
Ui
400 V
Ithe 6 A
Utilisation category AC-15
Ie
/Ue
6 A/400 VAC
Max. fuse rating 6 A gL/gG D-fuse
Ambient temperature –25 °C … +70 ºC
Mech. life > 100.000 operations
Max. wire length 20 m
Features wire pull and breakage function
Approvals Hd
Weight 180g
