Specifications

Instrument compatibility

• SR300, SR200, SR100, SR30, SR25, SR22, SR20, SR15, SR12, SR11, or SR05 pyranometer; SR05 ball levelling

Tube compatibility

• diameter 27 to 60 mm

Tilt angles

• 0 to 90 °

Material

• anodised aluminium

Rated operating temperature range

• -40 to +80 °C

Included parts

• bracket; 1 x M6 central spring loaded bolt; 4 x M5 bolt; 2 x tube clamp

Options

With the optional addition of VMA01 mounting adapter plate, VU01 ventilated pyranometers can also be in installed on PMF01

There are other mounting options available for our sensors. They allow for simplified mounting, levelling and instrument exchange on a flat surface or a tube.
