Full Load Output: 1.0 nom mV/V
Zero Load Output: <±5.0%
Excitation (Max): 10 (15) V
Accuracy: ±1% FS
Repeatability: <0.25%
Input Resistance: 375 (±20) Ω
Output Resistance: 350 (±2) Ω
Compensated Temp. Range: -10° to 40°C
Operating Temp. Range: -20° to 60°C
Temp. Coefficient on Zero: <0.0010%Capacity/°C
Temp. Coefficient on Span: <0.0010%Capacity/°C
Safe Overload: 150%
Insulation: >500 @ 100Vdc MΩ
IP Class: IP68

Item No:          Wire (mm) Capacity (kg.) Dimensions (mm)
WT3-27-28       27-28          9700           L230 x H116
WT3-29-32       29-32         12600           L230 x H116
WT3-33-35       33-35         15100          L230 x H116
WT3-36-38       36-38         17900           L230 x H116
