Measurand

• hemispherical solar radiation
• sensor tilt angle (3 components x, y and z)

ISO 9060:2018 classification

• spectrally flat Class A pyranometer

IEC 61724-1:2021 compliance

• meets Class A PV monitoring system requirements

IEC 61724-1:2021 compliance

• - for solar irradiance for all locations and climatic conditions - for single axis tracker and pyranometer tilt angle measurement

Dome protector

• included (model DP01)

Status LED

• power & communication

Instrument diagnostics

• leakage, tilt, rotation, heating, internal humidity

Heating

• included

Calibration certificate

• included (content limited according to ISO/IEC 17025, section 7.8.1.3)

Temperature response test of individual instrument

• report included

Temperature response

• < ± 0.4 % (-30 to +50 °C)

Directional response test of individual instrument

• report included to 95 °

Accelerometer test of individual instrument

• report included

Tilt measurement uncertainty

• ± 1 ° (0 to 180 °) (-30 to +50 °C)

Available cable lengths (not included)

• 3, 5, 10 or 20 m

Equipment classification

• Industrial Equipment

Surge Immunity

• Level 2, test level 1 kV

with optional SPD01*

• Level 4, test level 4 kV

Safety compliance

• EU Low Voltage Directive (2014/35/EU) / USA National Electric Code (NFPA70)

Earthing terminal

• included on instrument

Normal -heated, ventilated

• < 3 W

Medium -unheated, ventilated

• < 1 W

Low -unheated, unventilated

• < 0.5 W

Communication protocol

• Modbus RTU

RS-485 isolation voltage

• 1.5 kV

Hardware interface

• 2-wire RS-485

Options

We offer accessories for use with the SR200-D1, including electrical and mounting hardware options.

•    SPD01 Surge Protection Device (for 1 to 3 instruments) for cables longer than 3 meters and to upgrade Surge Protection to level 4
•    PID01 Pyranometer Isolation Disc, electrically insulating the instrument from the mounting platform, spring-loaded for easy levelling
•    LM01 spring-loaded levelling mount; a practical mount for easy mounting, levelling, and instrument exchange on flat surfaces
•    TLM01 tube levelling mount with a set of bolts
•    calibration certificate including customer name and contact information
•    DP01 dome protector, set of 5 pieces
•    AMF03 albedometer fixture
•    PMF01 and PFM02 mounting fixtures
