Accessories Type AMK part no. Remarks

Power cable for X1, 6-wired

IDT-LE2000 201105 Length: 2 m, angular connector

IDT-LE5000 201711 Length: 5 m, angular connector

IDT-LE10000 201106 Length: 10 m, angular connector

IDT Starter KIT 46980 Power cable IDT-LE2000 assembled with cable end sleeves

Assembled IDT power cable 46864 Power cable IDT/distributor box. Power cable assembles at each end, ength 2 m, M23 angular connector 90°, M25 screwed cable gland with bus connector. Customised lengths upon request

Assembly group IDT cable 401209 1 x M23 angular connector 90° 1 x M25 screwed cable gland 1 x bus connector 6 x bus pin

CAN-BUS cable for X2/X3, A-coded

IDT-ACC500 201107 Length: 0.5 m, angular connector

IDT-ACC2000 201108 Length: 2 m, angular connector

IDT-ACC5000 201131 Length: 5 m, angular connector

IDT-ACC10000 202338 Length: 10 m, angular connector

IDT-ACCT 201110 Bus-terminating plug (pins) for X2 plug straight

I/O cable for X4 B-coded

IDT-EA500 202054 Length 0.5 m, angular connector 90°, 8-pin

IDT-EA2000 202647 Length 2 m, angular connector 90°, 8-pin

IDT-EA5000 201731 Length 5 m, angular connector 90°, 8-pin

IDT-EA10000 202281 Length 10 m, angular connector 90°, 8-pin

Power supply Power supply 48 V/10 A O808 IDT supply input 1 x 230 V/output 48 V/480 W

Power supply 48 V/20 A O809 IDT supply input 3 x 400 V/output 48 V/1000 W

Braking chopper IDT-BR50 O822 Supply voltage limitation (brake threshold as of 55 VDC)

Braking resistor IDT-AR100 O775 Braking resistor 3 Ω/100 W to the connection on the distributor box

Distributor box 4-fold IDT-X4 O764 Distributes supply voltage to 4 IDTs, includes braking chopper andstand-by supply for the multiturn encoder

Service and startup

KIT PC startup tool O755 AMK PC software AIPEX (AMK startup and parameterization explorer) including converter USB-CAN, circuit board AP-CI6 and connection cable
