Type: C4P-SA04530A001200 Part no.: 1215807

Features

Application Normal industrial environment

System part Sender

Resolution 30 mm

Scanning range 30 m

Protective field height 450 mm

No blind zones Yes

Synchronization Optical synchronisation

Integrated laser alignment aid ✔

Items supplied

Sender

System plug 1200

Safety-related parameters

Type Type 4 (IEC 61496-1)

Safety integrity level

SIL3 (IEC 61508)

SILCL3 (IEC 62061)

Category Category 4 (ISO 13849-1)

Performance level PL e (ISO 13849-1)

PFHD (mean probability of a dangerous failure per hour)

Single device 9.6 x 10-9

Cascade with one guest 1.9 x 10-8

Cascade with two guest devices 2.9 x 10-8

TM (mission time) 20 years (ISO 13849-1)

Safe state in the event of a fault At least one OSSD is in the OFF state.

Functions

Protective operation ✔

Automatic calibration of the protective field width ✔

Beam coding ✔

Interfaces

System connection Male connector M12, 8-pin

Extension connection –

Configuration method DIP switch on system plug

Display elements LEDs

Fieldbus, industrial network

Integration via Flexi Soft safety controller CANopen 1)

DeviceNet™

EtherCAT®

EtherNet/IP™

Modbus TCP

PROFIBUS DP

PROFINET

1) For additional information on Flexi Soft -> www.sick.com/Flexi_Soft.

Electrical data

Protection class III (IEC 61140)

Supply voltage VS 24 V DC (19.2 V ... 28.8 V)

Ripple ≤ 10 %

Power consumption typical 1.31 W (DC)

Mechanical data

Dimensions See dimensional drawing

Housing material Aluminum extruded profile

Ambient data

Enclosure rating

IP65 (IEC 60529)

IP67 (IEC 60529)

Ambient operating temperature –30 °C ... +55 °C

Storage temperature –30 °C ... +70 °C

Air humidity 15 % ... 95 %, Non-condensing

Vibration resistance 5 g, 10 Hz ... 55 Hz (IEC 60068-2-6)

Shock resistance 10 g, 16 ms (IEC 60068-2-27)

Other information

Wave length 850 nm

Type of light Near-infrared (NIR), invisible

Integrated laser alignment aid ✔

Laser class 1

Wave length 650 nm

Type of light Visible red light

Classifications

ECl@ss 5.0 27272704

ECl@ss 5.1.4 27272704

ECl@ss 6.0 27272704

ECl@ss 6.2 27272704

ECl@ss 7.0 27272704

ECl@ss 8.0 27272704

ECl@ss 8.1 27272704

ECl@ss 9.0 27272704

ECl@ss 10.0 27272704

ECl@ss 11.0 27272704

ECl@ss 12.0 27272704

ETIM 5.0 EC002549

ETIM 6.0 EC002549

ETIM 7.0 EC002549

ETIM 8.0 EC002549

UNSPSC 16.0901 46171620
