Specifications

Surge immunity*

• :

Surge Immunity (EN-IEC 61000-4-5:2014)

• Level 4

Maximum line-to-line surge**

• 2 kV, 1 kA

Maximum line-to-ground surge**

• 4 kV, 2 KA

Number of protected instruments

• up to 3

Common mode signal voltage range

• ± 12 V

Differential mode signal voltage range

• ± 12 V

Maximum line-to-earth voltage

• 12 V

Housing material

• ASA/PC UL94 V0-1.5mm

Cable glands

• M12 (protected)

Cable diameter

• (3 to 6) mm

Optional SMF01: rated pole mount diameter

• (40 to 60) mm

Weight

• 0.7 kg

Rated operating DC input voltage range

• ± 30 V

Maximum DC input current

• 5 A

Total DC output current

• 5 A

Required over-current protection

• ≤ 5 A slow blow fuse

Rated operating temperature range

• (-40 to +80) °C

*tested with all Hukseflux Industrial pyranometers

**all lines tested as DC power lines

Options

• SMF01 SPD mounting fixture (tube mounting fixture with 2 x 40-60 mm tube clamp)
• PID01 Pyranometer Isolation Dis
