Media Aggressive Liquids & Gases

Valve Function Normally Closed

Voltage 12VDC

Piping Type Inline, Direct Piping

Port Size Barb for 1/8" ID Tube

Number of Ports 2 ports

Number of Positions 2 positions

Size (in) HxWxD 2.29 x 0.83 x 1.14

Type of Operation Direct Acting Type

Flow - GPM water @ 40 psig 0.0287

Flow - LPM water @ 40 psig 1.09

ESEOD (orifice) - in (mm) 0.05 (1.22)

Flow Coefficient (Cv) 0.035

Flow Capacity @ 40psi 1.45 LPM (Water); 50 LPM (Air)

Pressure Range (psi) Vacuum ~ 40psi

Response Time per Step (ms) 25

Operating Speed (cycles/min) 300

Ambient Temperature Range (⁰C) -20~65

Fluid Temperature Range (C⁰) -20~95

Wetted Materials PEEK body; Viton®GF Seals

Weight (oz) 3.5

Electrical Entry 22 AWG Lead Wires - 24" length

Voltage Range +10%, -10%

Power Consumption (w) 3.5

Internal Volume (Actuated) 0.017 cubic inches

Type 1
