Media Air, Inert Gas

Valve Function Single Solenoid Proportional, Normally Closed

Piping Type Inline, Direct Piping

Electrical Entry Orientation Standard, over port 2

Port Size 10-32 UNF

Number of Ports 2 ports

Number of Positions Variable

Approx Size (in) HxWxD 1.7 x 0.9 DIA

Type of Operation Direct Acting

Flow - SCFM @ pressure 1.06

Flow - LPM @ pressure 30

ESEOD (orifice) - in (mm) 0.032 (0.81)

Flow Coefficient (Cv) 0.015

Lubrication Not required

Ambient Temperature Range (⁰F) 32~125

Wetted Materials ENP brass, SST, Nickel plated steel, FKM

Weight (oz) 3.0

Electrical Entry 18" Red Lead Wires

Compliance RoHS, REACH

Maximum Flow (LPM) 30

Callibrated Pressure Setting (psi) 100.0

Input current for full flow (mA) 200

Nominal Resistance @ 72⁰F (Ohms) 50.0

Power Consumption @ Rated Voltage (w) 2.0

Maximum Power Consumption (w) 2.4

Typical Hysteresis (%) 8
