DVP-30

Part no.:: 705365

Product description: DVP-30-01.1

Characteristic Value / Characteristic / Information

Adjustment type Manual

Control type direct-acting

Design Plate mounted

eCl@ss Drosselventil(Standard,Hydraul

Functionality Poppet valve

Funktion Drosselventil

Grundsymbol

Nom. size 30

Pmax [bar] 350,00 bar

Product family

Q Produktfamilie [l/min] 0,00 - 300,00

Q Produktfamilie [l/min]

Qmax valves [l/min] 300,00 l/min

Sealing material FKM

Type of installation others

Version 1

Volumenstrombereich [l/min] 0,00 - 300,00

Volumenstrombereich [l/min]

The needle valve DVP-30 is a subplate mounted valve equipped with throttle spindle and turning knob. When the turning knob is screwed out, the flow rate is increased - depending on viscosity and pressure. Throttle and shut-off function in both directions. Qmax = 300 l/min Pmax = 350 bar
