Bộ truyền động Spring Return FSLF230 US Belimo, FSLF230 US Belimo, Spring Return FSLF230
Housing material
† UL File XAPX.E108966
AC 230 V
50/60 Hz
17 VA
4 W, 8 VA (60 Hz 5.5 VA), End stop 27 VA, 0.125 A slow blow fuse *
18 GA, 3 ft [1 m], 3 color coded wires electronic throughout 0...95° rotation grounded enclosure, 230 V
30 in-lb [3.5 Nm] from 32...350°F [0...177°C] selectable by ccw/cw mounting
reversible with cw/ccw mounting
95°
15 s / 90°
at rated voltage and torque 32...122°F [0...50°C] <15 s
45 dB(A)
62 dB(A)
3/8...1/2" round, centers on 1/2"
Mechanical
IP30
NEMA 1
UL Enclosure Type 1
cULus acc. to UL60730-1A/-2-14, CAN/CSA E60730-1:02, Listed to UL 2043 - suitable for use in air plenums per Section 300.22(C) of the NEC and Section 602 of the IMC.
NYC Department of Buildings MEA 197-07-M California State Fire Marshal Listing 3210-1593:102
ISO 9001
32...122°F [0...50°C] -40...176°F [-40...80°C]
Max. 95% RH, non-condensing maintenance-free
4.1 lb [1.8 kg] galvanized steel
