1050V2

100 mV/lbf sensitivity, 20 lbf compression range, 50 lbf tension range, 10–32 axial connector, 1/4–28 tapped hole top surface, 32 grams,–100 to +250°F Operation

1050V3

50 mV/lbf sensitivity, 100 lbf compression range, 100 lbf tension range, 10–32 axial connector, 1/4–28 tapped hole top surface, 32 grams,–100 to +250°F Operation

1050V4

10 mV/lbf sensitivity, 500 lbf compression range, 500 lbf tension range, 10–32 axial connector, 1/4–28 tapped hole top surface, 32 grams,–100 to +250°F Operation

1050V6

1 mV/lbf sensitivity, 5,000 lbf compression range, 500 lbf tension range, 10–32 axial connector, 1/4–28 tapped hole top surface, 32 grams,–100 to +250°F Operation
