1053V1

500 mV/lbf sensitivity, 10 lbf compression range, 10 lbf tension range, 10–32 radial connector, 10–32 tapped holes top and bottom, 28 grams,–100 to +250°F Operation

1053V2

100 mV/lbf sensitivity, 50 lbf compression range, 50 lbf tension range, 10–32 radial connector, 10–32 tapped holes top and bottom, 28 grams,–100 to +250°F Operation

1053V4

10 mV/lbf sensitivity, 500 lbf compression range, 200 lbf tension range, 10–32 radial connector, 10–32 tapped holes top and bottom, 28 grams,–100 to +250°F Operation

1053V5

5 mV/lbf sensitivity, 1,000 lbf compression range, 200 lbf tension range, 10–32 radial connector, 10–32 tapped holes top and bottom, 28 grams,–100 to +250°F Operation

1053V6

1 mV/lbf sensitivity, 5,000 lbf compression range, 200 lbf tension range, 10–32 radial connector, 10–32 tapped holes top and bottom, 28 grams,–100 to +250°F Operation
