CẢM BIẾN LỰC KIỂU VÒNG 1210V1 Dytran Instruments, 1210V1 Dytran, 1210V7 Dytran, RING STYLE FORCE SENSOR Dytran

The Dytran series 1210 is a ring style IEPE force sensor offered in sensitivities of .05 to 1.0 mV/lbf. The industry commonly refers to the sensors as "force washers", due to their similar appearance. Units were designed to measure rapid or slowly changing dynamic forces in machinery and other applications where a thru stud or bolt holds the sensor in place in a preloaded condition. The series 1210V can measure vibratory compressive forces over a wide frequency range and unidirectional pulsing forces from punch and forming presses and other repetitive force applications as well as impact forces. As an IEPE sensor, the series 1210V features built–in electronics, eliminating the need for an external charge amplifier and converter.

Design of the series 1210V features a quartz sensing element, operating in compression mode and packaged in a rugged stainless steel housing. Units utilize a 10–32 radial connector, thru hole mounting and are hermetically sealed for reliable operation in high humidity and dirty environments.
